Parking Assist Warning Indicator: Service and Repair
AR54.65-P-0004B Remove/Install Parktronic System (PTS) Warning Indicator In Rear Dome Lamp
AR54.65-P-0004B Remove/Install Parktronic System (PTS) Warning Indicator In Rear Dome Lamp
- with CODE (220a) Parktronic System (PTS)
1
Pull rear dome lamp (E15/3) together with PTS warning indicator (A44/3) out of headliner
NOTE: Pull left side out of headliner first (arrow)
2
Disconnect connectors from dome lamp and PTS warning indicator
3
Unclip cover (1) at rear dome lamp
4
Unclip PTS warning indicator from dome lamp
5
Reinstall in opposite order
