Engine Control Module: Description and Operation
AH07.61-P-0002-02MU ME-SFI Vehicle Features
AH07.61-P-0002-02MU ME-SFI Vehicle Features
- with CODE (494) USA version
(United States of America)
Functions/components for national version United States of America:
^
CHECK ENGINE indicator lamp (A1e26)
^
Fuel system open warning (fuel tank cap indicator)
^
Purge system with leak test.
Additional components:
-
Fuel tank pressure sensor (B4/3)
-
Activated charcoal canister shutoff valve (Y58/4)
^
Vent line to activated charcoal canister without vent valve and with large diameter.
^
During refueling the fuel vapors are collected at the filler neck and passed to the activated charcoal filter (ORVR = Onboard Refueling Vapor
Recovery).
^
The activated charcoal canister is enlarged.
