SL 600 (230.476) V12-5.5L Turbo (275.951) (2004)
/v12-5.5l_turbo_(275.951)/Page-3528001.png)
Air Register: Service and Repair
AR83.10-P-4740R Remove/Install Side Air Nozzle
AR83.10-P-4740R Remove/Install Side Air Nozzle
1
Unclip cover (2) using assembly wedge
2
Unscrew screw (3)
3
Press air nozzle (1) out of the instrument panel
4
Install in the reverse order.
Special Tools
Assembly Wedge, P/N# 110 589 03 59 00
