SL 600 (230.476) V12-5.5L Turbo (275.951) (2004)
/v12-5.5l_turbo_(275.951)/Page-331001.png)
Parking Assist Switch: All Technical Service Bulletins
Parktronic System(R) - Intermittently Inoperative
Date: March 16, 2004
Order No.: P-B-42.20/35
Supersedes:
Group: 42
SUBJECT:
Model 230.474/475/476 with Parktronic System
Model 211.065/070/076/082/083/265/282/283 with Parktronic System
Model Year 2003 and 2004
Parktronic System Intermittently Nonfunctional
If you encounter customer reports in the above model vehicles of the Parktronic system intermittently not functioning, check the switch at the foot
operated parking brake for ease of movement. If the switch exhibits resistance during its range of travel, replace the switch.
Note:
The contact switch of the foot-operated parking brake may respond with significant delay when released. This occurs when the contact switch only
travels a short distance, for example if the foot-operated parking brake is only released from the first notch.
Note:
The Parktronic system is deactivated when the foot-operated parking brake is applied.
Parts Information
In Case of Warranty
