Mariner 2WD V6-3.0L VIN 1 (2006)
Removal
CAUTION: During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning
gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.
1. With the vehicle in NEUTRAL, position it on a hoist.
2. Release the fuel system pressure.
3. Disconnect the battery ground cable.
4. Remove the crankshaft front seal.
5. Remove the 5 bolts and the pin-type retainer and the RH lower splash shield.
6. Remove the generator upper air duct bolt and the air duct.
7. Remove the generator shield pin-type retainer, bolt and the generator shield.
8. Remove the 2 generator bolts.
