Mariner 2WD V6-3.0L VIN 1 (2006)
3
Install the weatherstrip.
Late build vehicles
12. Remove the restraint system diagnostic tool from the vehicle harness side of the passenger side safety canopy module electrical connector.
13. Connect the passenger side safety canopy module electrical connector.
Early build vehicles
14. Remove the restraint system diagnostic tool from the vehicle harness side of the passenger side safety canopy module electrical connector.
15. Connect the passenger side safety canopy module electrical connector.
1
Connect the passenger side safety canopy module electrical connector.
2
Slide and engage the passenger side safety canopy module electrical connector locking clip.
