Mariner 2WD V6-3.0L VIN 1 (2006)
14. Release the seat latch cable from the retractor.
15. Remove the 2 nuts and the safety belt guide.
-
To install, tighten to 40 Nm (30 lb-ft).
16. Remove the nut and the rear center safety belt retractor.
-
To install, tighten to 40 Nm (30 lb-ft).
17. To install, reverse the removal procedure.
18. Check the active restraint system for correct operation.
-
Make sure that after the rear safety belt retractor is installed, the retractor is not in the automatic locking retractor (ALR) mode.
Safety Belt Retractor - Front
SAFETY BELT RETRACTOR - FRONT
Torx Bit, Safety Belt Bolt
Special Tool(s)
