Mariner 2WD V6-3.0L VIN 1 (2006)
7. Bend the retaining tab away from the pressure sensor, then slide the pressure sensor off the bracket.
8. CAUTION: Care must be taken to prevent damage to the seat cushion pan when removing the rivets.
Remove the 2 rivets and detach OCS ECU from the seat cushion pan.
9. Remove the OCS.
-
Pull all the OCS components (hose, pressure sensor, wire harness, ECU and connectors) through the seat cushion pan opening.
Installation
1. Bend the retaining tab back on the pressure sensor component bracket.
