Milan AWD L4-2.3L (2008)
14. NOTE: Battery mounting bracket removed for clarity.
Connect the electrical connectors to the PCM.
^
Attach the wiring harness retainer to the PCM bracket.
15. Install the battery tray and battery. For additional information, refer to Battery.
16. CAUTION: The steering gear/dash seal must be fully seated in the steering gear valve tower groove before the retaining clips are fully
engaged into the body. If the steering gear/dash seal is not seated to the steering gear valve tower groove and the clips are not fully
engaged to the body, water and foreign material may enter the passenger compartment and damage the vehicle interior.
Applying hand force to the center of the seal, install the steering gear/dash seal onto the steering gear valve tower until the seal is fully seated in
the valve tower groove.
17. CAUTION: The steering gear/dash seal must be fully seated in the steering gear valve tower groove before the retaining clips are fully
engaged into the body. If the steering gear/dash seal is not seated to the steering gear valve tower groove and the clips are not fully
engaged to the body, water and foreign material may enter the passenger compartment and damage the vehicle interior.
Install the steering gear/dash seal until the retaining clips are fully engaged into the body.
18. CAUTION: Do not allow the steering column to rotate while the steering column shaft is disconnected from the steering gear or damage
to the clockspring may occur. If there is evidence that the steering column has rotated, the clockspring must be removed and recentered.
