3. Remove the front and rear lower control arm nuts.

4. NOTE:  Once pressure is applied to the ball joint with the special tool, it may be necessary to tap the wheel knuckle at the ball joint area to

separate the ball joint from the wheel knuckle.

Using the special tools, disconnect the 2 lower ball joints.

5. Using the special tool, separate the halfshaft from the wheel hub.
