Page 5
background image

16. Remove the front door module. If installing a new door module, transfer parts as necessary.
17. To install, reverse the removal procedure.

-

If installing a new LH front window motor, it must be initialized. For additional information, refer to Window Motor Initialization. If installing
the original LH front window motor, it must be de-initialized, then initialized. For additional information, refer to Window Motor
Initialization.  See: Power Window Motor/Testing and Inspection
