Cooper S Convertible (R57) L4-1.6L Turbo (N14) (2009)

Page 3
background image

Release screws (1) and remove stabilizer link (2).
Tightening torque 22 11 6AZ See: Engine, Cooling and Exhaust/Engine/Drive Belts, Mounts, Brackets and Accessories/Engine Mount/Specifications.

Installation:

First mount front axle carrier on engine carrier and then tighten down screws (1).

Release screws (1) on bumper holder on left.
Tightening torque 51 11 4AZ See: Body and Frame/Bumper/Front Bumper/Specifications.
