Cooper S Convertible (R57) L4-1.6L Turbo (N14) (2009)
/l4-1.6l_turbo_(n14)/Page-1360005.png)
Fit wheel studs and evenly tighten crosswise by hand in order to center the disc wheel.
Tighten down wheel bolts in crosswise sequence with a calibrated torque wrench to prescribed tightening torque.
Tightening torque 36 10 1AZ See: Specifications.
Important!
The disc wheel must rest uniformly against the brake disc.
Use a torque wrench to evenly tighten wheel bolts in a crosswise sequence.
Important!
Changed wheel bolts with a diameter of M14 and 17 WAF!
Observe change tightening torque 36 10 1AZ See: Specifications.
Subsequent Installation of Wheel-Bolt Lock
36 13 - Subsequent installation of wheel-bolt lock
Loosen wheel bolts.
Raise car so that wheel can be turned freely.
Release wheel studs to such an extent that the wheel can move freely on the wheel hub.
Turn wheel so that valve is face down.
Remove top wheel stud and insert wheel stud lock.
