Drive Belt: Specifications

A/C BELT

Deflection At 22 Lbs.:

New, Inches ........................................................................................................................................................................................  0.197-0.217
Used, Inches ........................................................................................................................................................................................  0.236-0.276

ALTERNATOR BELT

Deflection At 22 Lbs.:

New, Inches ........................................................................................................................................................................................  0.295-0.354
Used, Inches ..................................................................................................................................................................................................  0.394

POWER STEERING BELT

Deflection At 22 Lbs.:

New, Inches ........................................................................................................................................................................................  0.236-0.354
Used, Inches ........................................................................................................................................................................................  0.236-0.354
