Lancer L4-2.4L SOHC (2005)
Required Special Tools:
-
MB990784: Ornament Remover
-
MB990480: Glass Holder
REMOVAL SERVICE POINTS
<<A>> REAR WINDOW LOWER MOLDING REMOVAL
CAUTION: If the drip molding has become warped, it should not be reused.
Use special tool MB990784 to lever out the molding.
<<B>> REAR WINDOW GLASS REMOVAL
Removal the rear window glass using the same procedure as for the windshield.
INSTALLATION SERVICE POINTS
>>A<< GLASS STOPPER/WINDOW DAM/REAR WINDOW UPPER MOLDING/REAR WINDOW GLASS INSTALLATION
