Montero Sport LTD 4WD V6-3.5L SOHC (1999)
Drive/Propeller Shaft: Description and Operation
GENERAL DESCRIPTION
RWD vehicles have a split three joint-type propeller shaft with a center bearing. 4WD vehicles have front and rear two-joint propeller shafts. The
front propeller shaft has a BJ-type joint on the transfer side.
CONSTRUCTION DIAGRAM
