Outlander 4WD L4-2.4L (4B12) (2008)
/Page-946001.png)
Flex Plate: Specifications
Drive Plate
Tighten drive plate bolts to temporary torque 40 Nm (30 ft-lb) in the order shown in the illustration.
Tighten drive plate bolts to specified torque in the order shown in the illustration.
Tightening torque ............................................................................................................................................................................ 130 Nm (96 ft-lb)
