Murano FWD V6-3.5L (VQ35DE) (2006)
Grille: Service and Repair
FRONT GRILLE
Removal and Installation
CAUTION: Apply protection tape around outer circumference of front grille (bumper fascia side).
REMOVAL
1. Apply protection tape around outer circumference of front grille (bumper fascia side).
2. Remove front grille-radiator cover clips and remove front grille-radiator cover.
3. Remove clips on upper side of front grille.
4. Remove clips of air duct and remove air duct.
5. Pull out grille pawls, and remove front grille assembly.
INSTALLATION
Install in the reverse order of removal.
