Pathfinder 2WD V6-4.0L (VQ40DE) (2009)
Cellular Phone Microphone: Service and Repair
Bose Audio With Navigation
MICROPHONE
Removal and Installation
REMOVAL
1. Remove the front roof console finisher. Refer to See: Body and Frame/Interior Moulding / Trim/Headliner/Service and Repair.
2. Detach the Bluetooth microphone (1) from the front console finisher tabs (A).
3. Detach the Bluetooth microphone connector (B) and remove the Bluetooth microphone (1).
INSTALLATION
Installation is in the reverse order of removal.
