Pathfinder 2WD V6-4.0L (VQ40DE) (2009)
HARNESS CONNECTOR (DIRECT-CONNECT SRS COMPONENT TYPE)
-
SRS direct-connect type harness connectors are used on certain SRS components such as air bag modules and seat belt pre-tensioners.
-
Always pull up to release black locking tab prior to removing connector from SRS component.
-
Always push down to lock black locking tab after installing connector to SRS component. When locked, the black locking tab is level with the
connector housing.
CAUTION:
-
Do not pull the harness or wires when removing connectors from SRS components.
