Ignition Switch: Service and Repair

Fig. 2 Ignition switch replacement

1.

Remove the four upper and lower shell cover retaining screws, then the shell covers.

2.

Disconnect electrical connectors from switch.

3.

Remove switch retaining screw from steering lock, Fig. 2.

4.

Remove switch.

5.

Reverse procedure to install.
