Electric Divert/Electric Air Switching (ED/ES) <--> [Air Diverter Valve]|Description and Operation > < Air Diverter Valve

Cutlass Ciera FWD V6-181 3.0L (1984)

Page 1
background image

Electric Divert/Electric Air Switching (ED/ES): Locations
Air Select Switching Valve

LH Front Of Engine.

 LH Side Of Engine Above Transmission

Applicable to:  1984-85 Cutlass Ciera w/V6-181
