Grand AM L4-121 2.0L (1988)
Headliner: All Technical Service Bulletins
Headliner - Sagging Repair Procedure
Bulletin Number:
88-10-42
Reference Number:
871001R
Publish Date:
7/88
Subject:
SAGGING HEADLINER REPAIR PROCEDURE
Models 1987-88 SUNBIRD AND GRAND AM
Affected:
EXCEPT 37 STYLE
Some headlining material may separate from the velcro retainers at the front or rear of the roof allowing it to sag.. In some cases the headlining may sag
due to insufficient support in the front or rear.
The following procedure is recommended to repair both conditions using service package part number 22541347. Parts are expected to be available on
July 25, 1988. Until then normal part orders will not be accepted by GMSPO. Only verifiable emergency VIP orders will be accepted. GMSPO will
make every effort to obtain parts. All parts will be placed on 400 control to waive VIP surcharges. However, the part will be shipped premium
transportation at dealer's expense. All other order types will be cancelled as incorrectly ordered while the 400 control is in place.
FIGURE 1
1.
Remove the old velcro and the grey foam behind it from the headliner (front and rear center) to obtain a smooth surface. Figure 1.
