Grand AM L4-121 2.0L (1988)
Exploded View Of Evaporator Core Legend. Part 2 Of 2.
INSTALL OR CONNECT
1. Heater core.
2. Heater core covers.
3. Lower heating duct and hoses.
4. Right sound insulator.
5. Hoist car.
6. Drain tube.
7. Heater hoses.
8. Lower car.
9. Add coolant to system.
