Vibe L4-1.8L VIN L (2003)
3. Install the connector cavity (2) to the lower portion of the body hinge pillar panel (1).
4. Install the body hinge pillar trim panel. Refer to Trim Replacement - Hinge Pillar (See: Interior Moulding / Trim/Trim Panel/Service and
Repair/Trim Replacement - Hinge Pillar) in Interior Trim.
5. Install the sunroof housing front drain hose (2) to the sunroof housing (1). Secure the drain hose with the clamp.
6. Install the headlining trim finish panel. Refer to Headliner Replacement (See: Interior Moulding / Trim/Headliner/Service and Repair) in Interior
Trim.
Sunroof Drain Hose Replacement - Rear
Sunroof Drain Hose Replacement - Rear
Removal Procedure
1. Remove the headlining trim finish panel. Refer to Headliner Replacement (See: Interior Moulding / Trim/Headliner/Service and Repair) in
Interior Trim.
2. Remove the sunroof housing rear drain hose clamp.
3. Remove the sunroof housing rear drain hose (2) from the sunroof housing (1).
4. Remove the lower and upper quarter trim panels. Refer to Trim Panel Replacement - Rear Quarter Lower (See: Interior Moulding / Trim/Trim
Panel/Service and Repair) and Trim Panel Replacement - Rear Quarter Upper (See: Interior Moulding / Trim/Trim Panel/Service and Repair/Trim
Panel Replacement - Rear Quarter Upper) in Interior Trim.
