Vibe L4-1.8L VIN L (2003)
Wheel Speed Sensor Replacement - Rear (AWD)
Removal Procedure
1. Remove the fuel tank filler pipe protector bolts (2) and remove the fuel tank filler pipe protector (1).
2. Remove the rear seat bottom and seat back. Refer to Seat Back Replacement - Rear Split Folding in Seats.
Important: The wheel speed sensor is serviceable only as an assembly. Do NOT attempt to service the sensor harness pigtail.
3. Disconnect the electrical connector (1) from the wheel speed sensor.
