Vibe L4-1.8L VIN L (2003)
2. Install the 2 new gaskets.
3. Install the accumulator and check ball assembly.
4. Align the groove of the manual valve with the pin of the manual valve lever.
5. Temporarily install the valve body with the 1 3 bolts.
^
Length of Bolt (1) 32 mm (1.26 inch)
^
Length of Bolt (2) 22 mm (0.87 inch)
^
Length of Bolt (3) 55 mm (2.17 inch)
^
Length of Bolt (4) 45 mm (1.77 inch)
