Vibe L4-1.8L VIN L (2003)
6. Temporarily install the detent spring (1) and the cover (2).
7. Make sure the manual valve lever contacts the center of the roller at the tip of the detent spring.
8. Tighten the 15 valve body retaining bolts.
^
Tighten the bolt to 11 Nm(97 inch lbs.).
9. Install the ATE temperature sensor, then the lock plate and bolt on the valve body.
^
Tighten the bolt to 11 Nm (97 inch lbs.).
10. Connect the 5 solenoid electrical connectors.
11. Install the fluid filter and pan.
12. Install the left engine splash shield.
13. Lower the vehicle.
14. Connect the negative (-) battery cable.
15. Refill the transaxle as necessary.
