Vibe FWD L4-2.4L (2009)
Danger: To avoid any vehicle damage, serious personal injury or death, always use the jackstands to support the vehicle when lifting the
vehicle with a jack.
Caution: When you are jacking the vehicle at the front locations, be certain that the jack or the jack lift pad does not contact the front fascia, front fascia
air dam, or the front fenders. If such contact occurs, vehicle damage may result. When jacking at selected front locations additional clearance may be
required for the jacking points.
When you are lifting a vehicle with a vehicle jack or a floor jack, block the wheels at the opposite end from which you are lifting. Use jack stands to
provide additional support.
Front of the Vehicle
Position the floor jack pad under the transmission support front bolts.
Rear of the Vehicle
For the base model, position the floor jack pad under the rectangular jacking point rearward of the twist beam axle and forward of the rear muffler. For
the GT model, position the floor jack pad under the rectangular jacking point forward of the rear muffler and between the rear lower control arm rear
pivot bolts. For the AWD model, position the floor jack pad under the rear differential support.
Safety Jack Stands
Front of the vehicle.
Position the safety jack stands (1, 2) as follows:
*
Rearward of the front tires.
*
Under the frame rails or under the rocker panel flange front side notch.
*
At the pantograph service jack lift points.
Rear of the Vehicle
Position the safety jack stands (1) as follows:
*
Forward of the rear tires.
*
Under the frame rails or under the rocker panel flange rear side notch.
*
At the pantograph service jack lift points.
