911 Carrera 4 Cabriolet (997) F6-3.6L (2006)
/f6-3.6l/Page-306009.png)
Sheetmetal Holder
10. Fit sheetmetal holder between servo lines into rubber mounts -arrow-.
Front Air-conditioning Compressor Fastening Screw And Sleeve
11. Fit air-conditioning compressor: before installing the compressor check whether the aluminium spacer sleeve -arrow-is inserted. Grease and fit
sleeve. Also lay the ground cable before installation.
Fastening Of The Air-conditioning Compressor
12. Fit air-conditioning compressor and fasten using three M8 Torx screws (two short ones at the rear, one long one at the front) -1-. See details and
tightening torques.
Air-conditioning Compressor Ground Line
13. Connect ground connector to intake distributor side 4-6-arrow-.
Drive Belt
