9-5 (9600) L4-2.3L Turbo (B235) HO (2003)
Windshield Washer Hose: Service and Repair
Windscreen Washer Hoses
To remove
1. Remove the bonnet insulation.
2. Disconnect the hoses from the nozzles in the bonnet.
3. Remove the front left-hand wing liner.
4. Disconnect the hose from the pump and pull out the hose.
To fit
