9-7X V8-6.0L (2008)
*
Most of AFLs connectors have EPC on their connector body. Some of the smaller connectors will not have any markings on them.
*
In some cases Bosch will actually be printed on the connector. If Bosch does not appear on the connector, look for the Bosch logo. The Bosch
logo is a circle with a blunted arrow inside. This logo can appear anywhere on the connector and is often very small.
*
In some cases Delphi will actually be printed on the connector. If Delphi is not printed on the connector, look for PED. In both cases there is no
specific orientation for Delphi or PED and they can appear anywhere on the connector.
