Aura L4-2.4L (2008)
3. Install the drive belt tensioner.
4. Install the drive belt tensioner bolt.
Tighten the bolt to 50 N.m (37 lb ft).
5. Install the drive belt idler pulley.
6. Install the drive belt idler pulley bolt.
Tighten the bolt to 50 N.m (37 lb ft).
7. Install the generator. Refer to Generator Replacement (LZ4) ()Generator Replacement (LY7) ().
8. Rotate the drive belt tensioner counterclockwise.
9. Install the accessory drive belt. Refer to Drive Belt Replacement (See: Engine, Cooling and Exhaust/Engine/Drive Belts, Mounts, Brackets and
Accessories/Drive Belt/Service and Repair).
10. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection (LAT) ()Battery Negative Cable
Disconnection and Connection (LZ4/LY7) ().
