Aura V6-3.5L (2007)
Alternator: Service and Repair
Generator Replacement (LZ4)
Generator Replacement (LZ4)
Removal Procedure
Important: Service the generator as a complete unit.
1. Disconnect the negative battery cable.
2. Remove the drive belt.
3. Remove the generator electrical connections.
4. Remove the generator mounting nuts and bolts.
5. Remove the generator.
Installation Procedure
Notice: Refer to Fastener Notice.
1. Install the generator.
*
Tighten the bolts to 50 N.m (37 lb ft).
*
Tighten the nuts to 30 N.m (22 lb ft).
