ION L4-2.4L (2007)
Headlamp Relay: Locations
Lighting Systems Component Views
Left Side of the I/P, Under the Tie Bar (T82)
1 - I/P Tie Bar
2 - Data Link Connector (DLC)
3 - Headlamp Relay
Headlamp Relay: Locations
Lighting Systems Component Views
Left Side of the I/P, Under the Tie Bar (T82)
1 - I/P Tie Bar
2 - Data Link Connector (DLC)
3 - Headlamp Relay
