L300 V6-3.0L VIN R (2001)
17. Remove right rear seat bolster.
17.1 Reach down into the outer corner of rear seat cushion to expose bolster retainer tab.
17.2 Bend tab upward.
17.3 Starting at the bottom, pull forward to disengage bolster from retainer tab, then pull upward to disengage upper attachment.
IMPORTANT: If the vehicle is a wagon, proceed to Step 19.
18. Remove rear compartment side carpet (sedan only).
18.1 Flip rear compartment floor carpet away from right side of vehicle.
18.2 Remove rear compartment side carpet fasteners as shown in illustration.
18.3 Remove side carpet assembly.
18.4 Proceed to Step 20, if vehicle is a sedan.
