Wheel Bearing: Service and Repair
Wheel Bearing/Hub Assembly

FRONT WHEEL BEARINGS AND/OR HUB

1. Using large driver (part number 6), press in new bearing, as shown in illustration, until seated.

2. Press in hub as shown in illustration, using part numbers:

-

5 - knuckle support tube

-

7 - small driver

IMPORTANT:  When performing this operation, the small driver (part number 7) must be used to support the bearing inner race with its small
(pilot) side facing towards the press, away from bearing.
