VUE FWD V6-3.5L (2008)
3. Position the lower ball joint stud into the steering knuckle.
Notice: Refer to Fastener Notice (See: Service Precautions/Vehicle Damage Warnings/Fastener Notice) .
4. Using theSA9140E , install the ball stud nut.
Tighten the nut to 40 N.m (30 lb ft) .
5. Tighten the strut to steering knuckle bolts and nuts.
Tighten the bolts and nuts to 180 N.m (133 lb ft).
Important: Do not loosen the castle nut for cotter pin installation.
6. Tighten the castle nut enough to allow for cotter pin installation.
Important: The cotter pin must not contact the wheel speed sensor or drive axle.
