xB L4-1.5L (1NZ-FE) (2004)
/Page-473001.png)
Valve Clearance: Adjustments
VALVE CLEARANCE
ADJUSTMENT
1. REMOVE CYLINDER HEAD COVER NO.2
a. Remove the 4 nuts and cylinder head cover No. 2.
2. REMOVE IGNITION COIL NO.1
a. Remove the 4 bolts and pull out the 4 ignition coils.
3. DISCONNECT VENTILATION HOSE
a. Disconnect the ventilation hose from the cylinder head cover.
4. DISCONNECT VENTILATION HOSE NO.2
a. Disconnect the ventilation hose No. 2 from the cylinder head cover.
