Forester F4-2.5L SOHC (2004)
Brake Pad: Testing and Inspection
Front
Front Brake Pad
INSPECTION
Check the pad thickness A.
NOTE:
^
Always replace the pads for both right and left wheels at the same time.
^
Also replace the pad clips if they are twisted or worn.
^
A wear indicator is provided on the inner disc brake pad. If the pad wears down to such an extent that the end of wear indicator contacts disc rotor,
a squeaking sound is produced as the wheel rotates. If this sound is heard, replace the pad.
^
Replace the pad if there is oil or grease on it.
