Heater Core: Service and Repair

Heater Core

REMOVAL

1. Remove the heater cooling unit.

2. Open the heater core pipe cover.

3. Loosen the screws to remove mode actuator.

4. Loosen the screws to remove foot duct.

5. Loosen the screws to remove evaporator cover.
