6. Connect the air assist hoses.

7. Install the fuel injectors

NOTE:  Replace the O-rings with new ones.

NOTE:  Do not forget to install the fuel injector securing clip

8. Tighten the bolt which installs the injector pipe on the intake manifold.

Tightening torque: 5.0 N.m (0.51 kgf.m, 3.7 ft.lb)
