Forester F4-2.5L SOHC (2004)
3. Install the belt idler (No. 1).
Tightening torque: 39 Nm (4.0 kgf-m, 28.9 ft. lbs.)
TIMING BELT
1. Preparation for the installation of automatic belt tension adjuster assembly.
2. Installation of timing belt
1. Turn the camshaft sprocket No. 2 using ST1, and then turn the camshaft sprocket No. 1 using ST2 so that their alignment marks (A) come to
top positions.
ST1 18231 AA010 CAMSHAFT SPROCKET WRENCH
NOTE: Also the CAMSHAFT SPROCKET WRENCH (499207100 can be used.
ST2 499207400 CAMSHAFT SPROCKET WRENCH
2. While aligning alignment mark on the timing belt (B) with marks on sprockets (A), position the timing belt properly.
3. Install the belt idler No. 2.
Tightening torque: 39 Nm (4.0 kgf-m, 28.9 ft. lbs.)
4. Install the belt idler (No. 2).
Tightening torque: 39 Nm (4.0 kgf-m, 28.9 ft. lbs.)
