Throttle Body|Removal and Installation|Page 2338 > < Throttle Body|Removal and Installation
Page 2
background image

8. Remove the bolts (B) which install throttle body to the intake manifold.

INSTALLATION

Install in the reverse order of removal.

NOTE:  Replace the gasket with a new one.

Tightening torque:
Throttle body: 22 N.m (2.2 kgf.m, 15.9 ft.lb)
