Forester F4-2.5L SOHC (2004)
3. Apply proper amount of liquid gasket to the entire oil pan mating surface.
Fluid packing: THREE BOND 1217B (Part No. K0877YA020)
4. Apply liquid gasket fully to three holes other than screw holes on transmission case.
Fluid packing: THREE BOND 1217B (Part No. K0877YA020)
5. Install the oil pan.
Tightening torque: 5 Nm (0.5 kgf-m, 3.6 ft. lbs.)
6. Install the front and rear vehicle speed sensor, and also the torque converter turbine speed sensor, and then fasten the harness.
Tightening torque: 7 Nm (0.7 kgf-m, 5.1 ft. lbs.)
7. Install a new aluminum washer and oil cooler pipes.
Tightening torque:
Ti: 25 N.m (2.5 kg f-rn, 18.1 ft. lbs.)
T2: 40 N.m (4.1 kg f-rn, 30 ft. lbs.)
T3: 44 N.m (4.5 kg f-rn, 32.5 ft.lbs.)
8. Install the transmission rear crossmember bolts.
Tightening torque: 75 Nm (7.6 kgf-m, 55 ft. lbs.)
9. Install the propeller shaft.
10. Install the shield cover.
11. Install the front, center, rear exhaust pipes and muffler.
