Forester F4-2.5L SOHC (2004)
3) Align the width across flat portion of ABSCM&H/U side stud bolt with the bolt hole groove on bracket, and then install the ABSCM&H/U.
NOTE: Confirm the specification mark of ABSCM&H/U.
Tightening torque: 18 Nm (1.8 kgf-m, 13.0 ft. lbs.)
4) Connect the brake pipes to their correct ABSCM&H/U connections.
Tightening torque: 15 Nm (1.5 kgf-m, 10.8 ft. lbs.)
5) Using the cable clip, secure the ABSCM&H/U harness to bracket.
6) Connect the connector to ABSCM&H/U.
NOTE:
^
Be sure to remove all foreign matter from inside of the connector before connecting.
^
Ensure that the ABSCM&H/U connector is securely locked.
7) Connect the ground cable to ABSCM&H/U, and then apply anti-corrosive wax.
8) Install the air intake duct.
9) Bleed air from the brake system.
