Forester F4-2.5L SOHC (2004)
Impact Sensor: Service and Repair
Sensors
Side Airbag Sensor
REMOVAL
1. Turn the ignition switch to OFF.
2. Disconnect the ground cable from battery, and wait for at least 20 seconds before starting work.
3. Remove the outer belt (FRONT).
4. Detach the side airbag sensor, and then disconnect the airbag connector.
INSTALLATION
CAUTION: Use new nuts when reassembling.
Install in the reverse order of removal.
Front Sub Sensor
REMOVAL
1. Turn the ignition switch to OFF.
2. Disconnect the ground cable from battery, and wait for atleast 20 seconds before starting work.
3. Remove the front grille and front grille side.
4. Disconnect the connector from front sub sensor.
5. Loosen the bolt, and then detach the front sub sensor.
INSTALLATION
