Forester F4-2.5L SOHC (2004)
10. Install the heat shield cover. (If equipped)
11. Install the rear exhaust pipe and muffler.
12. Inspect the following items. If the following inspection reveals problems, adjust the select cable and inhibitor switch.
1. The engine starts operating when select lever is in position "P" or"N", but not in other positions.
2. The back-up light is lit when the select lever is in position "R", but not in other positions.
3. Select lever and indicator positions are matched.
DISASSEMBLY
1. Remove the packing.
2. Remove the grip.
3. Remove the indicator light, and then remove the indicator cover.
NOTE: Be careful not to break the indicator light during removal.
4. Remove the slider.
5. Remove the cover.
