Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)
Brake Shoe: Service and Repair
REMOVAL
1. Loosen wheel nuts, jack-up vehicle, support it with rigid racks, and remove wheel.
2. Release parking brake.
3. Remove brake drum from brake assembly.
NOTE: If it is difficult to remove brake drum, remove adjusting hole cover from back plate, and then, turn adjusting screw using a slot-type
screwdriver until brake shoe separates from the drum.
4. Hold hold-down pin by securing rear of back plate with your hand.
5. Disconnect hold-down cup from hold-down pin by rotating hold-down cup.
6. Disconnect lower shoe return spring from shoes.
7. Remove shoes one by one from back plate with adjuster.
