Impreza 2.5 RS Coupe AWD F4-2.5L SOHC (2001)
7. Remove the rear cushion rubber.
B: INSTALLATION
1. PITCHING STOPPER
1. Install the pitching stopper.
Tightening torque:
T1: 49 Nm (5.0 kgf-m, 36.2 ft. lbs.)
T2: 57 Nm (5.8 kgf-m, 42 ft. lbs.)
2. Install the air intake duct and air cleaner case.
2. CROSSMEMBER AND CUSHION RUBBER
1. Install the rear cushion rubber.
Tightening torque: 38 Nm (3.9 kgf-m, 28 ft. lbs.)
2. Install the crossmember.
Tightening torque:
T1: 34 Nm (3.5 kgf-m, 25.3 ft. lbs.)
T2: 69 Nm (7.0 kgf-m, 51 ft. lbs.)
3. Remove the transmission jack.
4. Install the heat shield cover.
5. Install the center exhaust pipe, rear exhaust pipe and the muffler.
